NZ Wire -Tightlock Fencing

NZ Wire's Tightlock fence consists of line, stay and knot wires. Line wires are continuous in length and made from high tensile wire. The stay wires (vertical) are made from medium tensile wire and continuous in length. They combine with the knots and tension curves to create overall rigidity and elasticity. The knots are made from low tensile wire and can hold between 60-90kg per knot. The load of any impact will spread and dissipate over the full fence height and for some distance on either side.

Tech Spec

Features and Benefits

PROPERTIES	BENEFITS
Independent Knots	Increase structural strength of the fence. Allow wire to follow contours.
Fabricated Knots	Faster to erect. Less posts required. Lower total fence cost than wire and batten.
Tension Curves	Easy to strain. Allows for impact to dissipate over the fence and return to original condition.

Type and Application

TYPE	APPLICATION
Fawn	Used in deer fawning paddocks due to the tighter 240 mm stay wire combined with the 89 mm line wire prevents new born fawns from slipping through the fence.
Deer	1900 mm is the standard height. 1550 mm is used with a top wire to make up the 1900 mm height. A 150 mm stay wire is often used for additional security on boundary fence and raceways compared to a 300 mm stay for internal fence and sometimes used for boundary as an economical alternative. Used for deer and ostriches.
Top Up	Designed to make the extra height on top of a standard fence rather than replacing the entire fence. Used for deer and ostriches.
Field	Regional differences dicatate the different line wires and total heights. Combinations with barbed wires or electric wires complete the barrier for stock. Used in high stock pressure applications for cattle, sheep, goats and pigs.

WireMark® Quality Assurance

Technical Resources

NZ Wire -Tightlock Fencing

NZ WIRE Tightlock Netting Datasheet

View Download

Show more Show less

Line Wire Spacings

TYPE	DESCRIPTION	LINE WIRES	HEIGHT (mm)	STAY WIDTH (mm)	LENGTH (m)
DEER	A11 / 1550	11	1550	150 / 300	100
	A13 / 1900	13	1900	150 / 300	100
	A16 / 1900	16	1900	240	100
FIELD	A7 / 900	7	900	150 / 300	50 / 100
	A8 / 800	8	800	300	100
	A8 / 900	8	900	150 / 300	50 / 100
TOP UP	A5 / 600	5	600	300	200
TOP UP	A5 / 900	5	900	300	200
